SE-7441 Electrical Safety Analyzer



All-in-One Enhanced Simplicity, Safety, and Reliability

The SE 7441 Compact 4-in-1 Safety Analyzer combines cutting-edge safety features into one versatile device. With advanced ARC detection, precise ground bond measurements, and true negative voltage capabilities. Streamline your testing with one-click scanning, which simultaneously checks multiple points across up to 16 channels, boosting efficiency for multi-functional products. Ideal for today’s industrial environments, the SE 7441 features a user-friendly 4.3-inch touch panel and barcode data scanning, simplifying operations and maximizing productivity.

Documentation

Safety and Productivity Features

Continuous

Vericheck

Ramp High

Charge Low

Fast Discharge

ARC Detection

Smart GFI

External Scanner

Your Quality Assurance

Peak quality assurance for products with ARC detection capability eliminates poor gap spacing that may be damaged during shipping and cause dielectric breakdowns.

Simple and Intuitive Operation

Intuitive and user-friendly touch panel operation combined with highly flexible and programmable testing parameters to enhance testing efficiency.

Fast Discharge, Faster to Safety

EEC exclusive patent on fast discharge function helps the DUT rapidly discharge excess electricity within 50ms to maximize operator safety, especially when testing large capacitance DUTs.

Scan and Document

Built-in barcode interface supports a multitude of vendors and allows users to scan and capture data directly without connecting to a computer.

Enhancing Testing Efficiency

One-click scanning checks several points for potential weaknesses using up to 16 channels on multi-functional products, increasing testing efficiency.

True Negative Voltage Technology

Electric motor manufacturing sector benefits from EEC’s True Negative Voltage technology in insulation resistance (IR), which meets stator winding insulation standards IEEE Std. 43.

Specification

Can't decide which model is right for you?
We are here to help

CONTACT US



For more details download the full documentation here



7441
ACW5kVac/40mA
DCW6kVdc/10mA
IR6kVdc/50GΩ
GB32A/600mΩ/8Vac
Dimension (WxHxD, mm)430x133x400
Weight20kg

* SE-7441 Built-in 8W+8G scanner
